Establishing the Power Supply

Note the safety instructions. Safety Instructions for the Electrical Power Supply

WARNING

warning

Electric shock due to damaged or improperly installed cable

The use of damaged or improperly installed cables may result in a potentially fatal electric shock.

  1. Check all live cables and connections for proper installation and damage.
  2. Have any damaged, deformed, or worn parts replaced by a qualified electrician only.

WARNING

warning

Fire hazard due to improper mains connection

A fire can be caused by an improper mains connection. Serious burns can be the result.

  1. Make sure that the operating voltage stated on the rating plate matches the mains voltage.

For mains connection and fuse protection, see:

Technical data

Circuit diagram 115 V

Circuit diagram 230 V

115 V version

The mains plug is not attached to the power supply cable.

Attach an appropriate mains plug (customer-specific) to the power supply cable and plug it in.

230 V version

The mains plug is attached to the power supply cable.

  1. Ensure that the device is connected to a power supply with an impedance that is less than or equal to Zmax or that the continuous current rating of the supply at the connection point to the power grid is sufficient for connecting the device.
  2. Ensure that the short-circuit power Rsce at the connection point to the power grid is greater than or equal to 234 in order to comply with the EMC requirements as stated in IEC 61000‑3‑12.

Plug in the mains plug.
